Product Details
Place of Origin: China
Brand Name: Dingang
Certification: SGS,ITS,BV
Model Number: 1.5mm×1250mm-3003
Payment & Shipping Terms
Minimum Order Quantity: 1000 Kgs / 1 Metric Ton
Price: Negotiable
Packaging Details: Seaworthy Packing With Wooden Pallet
Delivery Time: Within 35 Days After Order Confirmed And Down Paymetn Received
Payment Terms: L/C,T/T,Western Union,MoneyGram
Supply Ability: 5000 Tons / Per Month
Name: |
1.5mm×1250mm-3003 Aluminum Coated Color Coil |
Alloy: |
3003 |
Thickness: |
1.5mm |
Width: |
1250mm |
Color: |
Sliver |
Shape: |
Coil |
Process: |
Rolling |
Paint Coating: |
PE |
Recyclable: |
Yes |
Application: |
Decoration In The Field Of Architecture/Billboards And Signage/Transportation/Home Appliance And Electronics Industry/Industrial Equipment Field Etc |
Name: |
1.5mm×1250mm-3003 Aluminum Coated Color Coil |
Alloy: |
3003 |
Thickness: |
1.5mm |
Width: |
1250mm |
Color: |
Sliver |
Shape: |
Coil |
Process: |
Rolling |
Paint Coating: |
PE |
Recyclable: |
Yes |
Application: |
Decoration In The Field Of Architecture/Billboards And Signage/Transportation/Home Appliance And Electronics Industry/Industrial Equipment Field Etc |
Key features:
Chemical composition: Mn (1.0-1.5%), Cu (0.05-0.20%), optimized corrosion resistance and formability.
Mechanical properties: tensile strength ≥ 110 MPa, elongation ≥ 20%, suitable for cold rolling, stamping and other processing.
Coating process: PVDF (super weather resistance), PE (economical), support RAL/Pantone color card customization.
Surface treatment: smooth, matte or embossed (e.g. wood grain, stone grain) to enhance the decorative effect.
International Certifications:
ASTM B209 (American Standard Aluminum Sheet Specification), EN 485 (European Standard for Aluminum), JIS H4000 (Japanese Standard).
Environmental certification: RoHS, REACH compliant, support LEED green building score.
Product Parameters:
| Product | 1.5mm×1250mm-3003 Aluminum Coated Color Coil |
| Thickness | 0.5-1.6mm |
| Width | 100-1600mm |
| Material | 3003,3004,3105 |
| Temper | O, H12, H14, H16, H18, H24, H26, H32, H34, etc |
| Inner Diameter | 405mm,505mm,150mm,etc. |
| Color | RAL, Pantone Color Or As Alient's Demand |
| Coating thickness | PVDF Paint Coating: Not Less Than 25um |
| PE Paint Coating : Not Less Than 18um | |
| Packing | Export Standard Wooden Pallets (Eye To Wall,Eye To Sky) |
| Payment Terms | L/C at sight or 30% T/T in advance as deposit, and 70% balance against the B/L copy. |
| MOQ | 1 Ton Per Specification |
| Delivery Time | Within 30 Days |
| Loading Port | Shanghai Port |
| Application | Aluminum Roofing,ACP,Roller Shutter Window,Roller Shutter Door,Aluminum Ceiling,Aluminum Grilling,Aluminum Downspout System,Home Appliance's Plate, body tank of cold chain truck,high speed rail,aluminum pull ring,food packaging,outer packing case of capacitor,external contour of letter channel |
Core Benefits:
| Advantage | Detailed description |
| Lightweight and strong | The density is only 1/3 of steel, and the tensile strength is high, which is suitable for long-span structures (such as roofs and curtain walls). |
| Excellent corrosion resistance | Natural oxide film coating double protection against acid rain, salt spray and industrial pollution (suitable for coastal and high humidity areas). |
| Aesthetic diversity | Customizable colors (metallic, matte) and textures are available to meet the visual needs of high-end architecture and consumer goods. |
| Ease of processing | Support cutting, bending, welding, adapt to automated production lines, reduce processing costs. |
| Environmentally sustainable | 100% recyclable, reducing carbon footprint and complying with EU Circular Economy Act. |
Application scenarios and cases in the international market
1. Architecture and curtain wall field
Applications: Exterior wall cladding, roofing materials, sun visors.
Case:
Project: "EUREF Campus", a commercial building in Berlin, Germany.
Solution: PVDF-coated 3003 aluminum coil (matte silver) to create an energy-saving curtain wall.
Results: 80% solar radiation is reflected, building energy consumption is reduced by 25%, DGNB sustainability certification.
2. Transportation
Applications: high-speed rail compartment exterior panels, truck bodies, ship decks.
Case:
Project: Carriage shell of the N700S train on the Shinkansen in Japan.
Solution: 1.5mm 3003 aluminum coil (dark blue PE coating) replaces stainless steel with 30% weight reduction.
The result: increased speed and energy efficiency, and compliance with JIS E 4031 fire protection standards.
3. Industrial & Energy Equipment
Application: Solar Mount, Chemical Storage Tank, Electrical Cabinet Enclosure.
Case:
Project: Texas Solar Power Station, USA.
Solution: White PVDF coated aluminum coil for PV bracket, high temperature resistance (-40°C to 120°C).
The result: an extension of stent life to 30 years and a 40% reduction in maintenance costs.
4. Home Appliances & Consumer Goods
Applications: refrigerator panels, air conditioning enclosures, kitchenware.
Case:
Brand: LG Electronics refrigerator series.
Solution: Matte black 3003 aluminum coil is used for high-end refrigerator door panels.
Results: Anti-fingerprint design, increased product premium, and annual sales increased by 15%.
International Standards & Compliance
Construction standards: EN 1396 (European specification for coated aluminum coils), AAMA 2605 (American standard for high-performance coatings).
Environmental certifications: Cradle to Cradle® (material health), EPD (Environmental Product Declaration).
Industry Testing: Salt Spray Test (ASTM B117), Weather Resistance Test (ISO 9227).
Get Started:
Contact us for free samples, custom color cards and international certification documents to start your global project cooperation!
